1-1-1 T2100SP
SPECIFICATIONS
*ˆ Mode---------SP mode unless otherwise specified
* Test input terminal
<Except Tuner>--------Video input (1 Vp-p)
Audio input (-10 dB)
<Tuner>------------------Ant. input (80 dBµV) Video: 87.5%
Audio: 25 kHz dev. (1 kHz Sin)
< DEFLECTION >
< VIDEO & CHROMA >
< DVD >
Description Condition Unit Nominal Limit
1. Over Scan --- % 90 5
2. Linearity
Horizontal % --- ±15
Vertical % --- ±10
3. High Voltage --- kV 29 ---
Description Condition Unit Nominal Limit
1. Misconvergence
Center m/m --- 0.4
Corner m/m --- 2.5
Side m/m --- 1.5
2. Tint Control Range --- deg ±30 ---
3. Contrast Control Range --- dB 6 2
4. Brightness (100% White Full Field) Contrast: Max ft-L 20 15
5. Color Temperature --- K 9200 ---
Description Condition Unit Nominal Limit
1. Horizontal Resolution (TDV-540 TIT.2 CHP.16) --- Line 350 330
2. Video S/N at CN3400 (TDV-540 TIT.2 CHP.6) --- dB 60 55
3. S/N Chroma at CN3400
(TDV-540 TIT.2 CHP.17)
AM --- dB 58 53
PM --- dB 58 53
4. Audio Distortion (LPCM 48 kHz, W/LPF)
(PTD 1-NOR TIT.1 CHP.1)
L
R
% 0.03 0.07
5. Audio freq. response (LPCM 48 kHz)
(PTD 1-NOR TIT.1 CHP.5 -- 10)
L, 20 Hz
R, 20 Hz
L, 20 kHz
R, 20 kHz
dB 0 +4/-5
6. Audio S/N (LPCM 48 kHz,W/LPF,A-WTD)
(PTD 1-NOR TIT.1 CHP.1 -- 2)
L
R
dB 85 75
