20050425 1-19-1 T2127EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DVD MAIN CBA UNIT
MMA CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DVD MAIN CBA UNIT N79U1JUP
Ref. No. Description Part No.
MMA CBA
Consists of the following:
1ESA10839
MAIN CBA
SENSOR CBA
----------
1ESA10448
Ref. No. Description Part No.
MAIN CBA
Consists of the following:
---------
CAPACITORS
C1001 ELECTROLYTIC CAP. 4.7µF/ 50V M CE1JMASDL4R7
C1002 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
C1003 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
C1004 CHIP CERAMIC CAP. F Z 0.01µF/ 50V CHD1JZ30F103
C1005 ELECTROLYTIC CAP. 220µF/ 6.3V M CE0KMASDL221
C1007 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1008 ELECTROLYTIC CAP. 10µF/ 50V M H7 CE1JMAVSL100
C1030 ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASDL471
C1031 CHIP CERAMIC CAP. F Z 0.01µF/ 50V CHD1JZ30F103
C1034 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1035 CHIP CERAMIC CAP. F Z 1µF/ 10V CHD1AZ30F105
C1037 CERAMIC CAP.(AX) F 10000pF/50V CCK1JZT0F103
C1038 CHIP CERAMIC CAP. F Z 0.01µF/ 50V CHD1JZ30F103
C1040 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1041 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1043 FILM CAP.(P) 0.018µF/ 50V J CMA1JJS00183
C1044 CHIP CERAMIC CAP.(1608) B K 0.047µF/ 50V CHD1JK30B473
C1045 CHIP CERAMIC CAP. CJ C 3.3pF/50V CHD1JC3CJ3R3
C1046 ELECTROLYTIC CAP. 1µF/ 50V M H7 CE1JMAVSL1R0
C1049 CERAMIC CAP.(AX) CH K 2.7pF/50V CCA1JKTCH2R7
C1050 CHIP CERAMIC CAP.(1608) CH D 5.6pF/50V CHD1JD3CH5R6
C1112 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1113 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1114 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1115 PCB JUMPER D0.6-P5.0 JW5.0T
C1116 ELECTROLYTIC CAP. 47µF/ 25V M CE1EMASDL470
C1117 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C1118 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C1203 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V CHD1JZ30F104
C1206 CHIP CERAMIC CAP. F Z 0.047µF/ 50V CHD1JZ30F473
C1207 ELECTROLYTIC CAP. 47µF/ 25V M CE1EMASDL470
C1208 ELECTROLYTIC CAP. 47µF/ 6.3V M H7 CE0KMAVSL470
C1210 CHIP CERAMIC CAP. F Z 1µF/ 10V CHD1AZ30F105
C1211 CHIP CERAMIC CAP.(1608) B K 0.022µF/ 50V CHD1JK30B223
C1212 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C1213 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C1214 ELECTROLYTIC CAP. 47µF/ 6.3V M H7 CE0KMAVSL470
C1216 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1217 CHIP CERAMIC CAP.(1608) CH D 10pF/50V CHD1JD3CH100
C1218 CHIP CERAMIC CAP. CH J 15pF/50V CHD1JJ3CH150
C1219 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1220 ELECTROLYTIC CAP. 47µF/ 6.3V M H7 CE0KMAVSL470
C1221 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1222 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1223 CHIP CERAMIC CAP. F Z 1µF/ 10V CHD1AZ30F105
C1224 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1225 CHIP CERAMIC CAP. CH J 560pF/50V CHD1JJ3CH561
C1226 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1233 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1234 CHIP CERAMIC CAP. F Z 1µF/ 10V CHD1AZ30F105
C1235 CHIP CERAMIC CAP.(1608) B K 0.022µF/ 50V CHD1JK30B223
C1239 ELECTROLYTIC CAP. 22µF/ 16V M H7 CE1CMAVSL220
C1240 CHIP CERAMIC CAP. CH J 560pF/50V CHD1JJ3CH561
C1241 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C1243 ELECTROLYTIC CAP. 22µF/ 16V M LL CE1CMASLL220
C1244 CERAMIC CAP.(AX) Y M 0.01µF/ 16V CCA1CMT0Y103
C1245 ELECTROLYTIC CAP. 47µF/ 25V M CE1EMASDL470
C1246 CERAMIC CAP.(AX) Y M 0.01µF/ 16V CCA1CMT0Y103
C1247 ELECTROLYTIC CAP. 22µF/ 50V M CE1JMASDL220
C1248 CERAMIC CAP.(AX) B 0.01µF/ 50V CCK1JKT0B103
C1249 CERAMIC CAP.(AX) Y M 0.01µF/ 16V CCA1CMT0Y103
C1251 CHIP CERAMIC CAP.(1608) B K 2700pF/50V CHD1JK30B272
C1252 ELECTROLYTIC CAP. 470µF/ 16V M CE1CMASDL471
C1253 ELECTROLYTIC CAP. 100µF/ 10V M CE1AMASDL101
C1254 ELECTROLYTIC CAP. 47µF/ 25V M CE1EMASDL470
C1257 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1258 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1261 ELECTROLYTIC CAP. 22µF/ 16V M H7 CE1CMAVSL220
C1264 CHIP CERAMIC CAP. F Z 0.047µF/ 50V CHD1JZ30F473
C1299 ELECTROLYTIC CAP. 4.7µF/ 50V M CE1JMASDL4R7
C1301 CHIP CERAMIC CAP. F Z 0.01µF/ 50V CHD1JZ30F103
C1309 CHIP CERAMIC CAP. F Z 1µF/ 10V CHD1AZ30F105
C1310 CHIP CERAMIC CAP. F Z 1µF/ 10V CHD1AZ30F105
C1311 ELECTROLYTIC CAP. 470µF/ 10V M CE1AMASDL471
C1312 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C1313 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C1314 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1316 ELECTROLYTIC CAP. 2.2µF/ 50V M CE1JMASDL2R2
C1317 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V CHD1JZ30F104
C1318 ELECTROLYTIC CAP. 100µF/ 10V M CE1AMASDL101
C1319 CHIP CERAMIC CAP. F Z 1µF/ 10V CHD1AZ30F105
C1321 ELECTROLYTIC CAP. 330µF/ 6.3V M CE0KMASDL331
C1322 CERAMIC CAP.(AX) Y M 0.01µF/ 16V CCA1CMT0Y103
Ref. No. Description Part No.
To Next Page
