20050425 1-18-2 T2127CA
Table 1 (V501 and L551 Combination)
Note 1: Purity and Convergence Adjustments must be
performed following CRT replacement. Refer to
Electrical Adjustment Instructions.
Note 2: Please confirm CRT Type No. on the CRT
Warning Label which is located on the CRT. Then See
the Table 1 for V501 and L551 combination chart.
Please refer this CRT, Deflection Yoke combination
chart for parts order.
CRT Warning Label Location
V501: CRT Type No. V501: CRT Part No.
L551: Deflection
Yoke Part No.
A59KPR84X TCRT190SM029 LLBY00ZQS016
A59KYL220X TCRT190GS040 LLBY00ZGS007
CRT
CRT Warning Label
CRT Type No.
To Next Page
