WIRING DIAGRAM < DVD Section >
DVD MAIN CBA UNIT
CONTINUE WIRING DIAGRAM <TV/VCR SECTION>
TO CN1
CN301
3 4
TRAY-IN GND SL(-)
5 6
SP(-)
7
SP(+)
8 SL(+)
TRAY-IN
DRIVE CBA
M
SLED MOTOR
M
SPINDLE MOTOR
EV+1.2V
EV+1.2V EV+3.3V
DVD-ON+3.3V
DVD-ON+5V
EV+9V
GND
1 2 3 4 5 6 7
GND
GND
PWRCON
8
15
9
10 11 12
CN1A
PICK UP UNIT
CN201
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20
TS(+) TS(-) FS(-) CD-LD FS(+) GND(DVD-PD) GND(CD-PD) PD-MONI DVD-LD VREF E GND B P-ON+5V CD/DVD D A C F GND(LD)
DETECTOR
FSTS
7 9
11
2 3 6 5 4
TO CN2
DVD-Y
GND
DVD-C
GND
DVD-AUDIO-MUTE
1 2 3 4 5
CN2A
DVD-AUDIO(L)
AUDIO+5V
DVD-AUDIO(R)
SPDIF
6 7 8 9
SCLK
CS
SDATA
DVD-REMOTE
14 13
P-ON+5V
DVD MECHANISM
