20050425 1-18-1 T2127CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1X FRONT CABINET ASSEMBLY T2127UH 1EM120189
A1-1 FRONT CABINET T2120UA 1EM020133
A1-2 CONTROL PLATE T2120UA 1EM220100
A1-3 BADGE L BRAND T2127UH-SYMPHONIC- 1EM420968
A1-4 CASSETTE DOOR T2120UA 1EM420772
A1-5 SPRING DOOR(Z10) T5200UA 0EM406687
A1-6 CLOTH(4X7XT0.7) T5000UA 0EM404974
A1-7 TRAY PANEL T2120UA 1EM320168
A1-8 TRAY SPRING TD707UH 0EM408552
A1-9 CLOTH(B) L5201U0 15X10X1.0T 0EM400076
A2 REAR CABINET T2120UA 1EM120116
A3# RATING LABEL T2127UH ---------
1B1 DECK ASSEMBLY CZD014/VM2466 N2466FT
1B2 DVD MECHA E6(TRP-COMBO) N79U0JVM N79U0JVM
B1 SPRING TENSION B0080B0 EM40808 26WH006
B2 SCREW M7 CRT(D22) T7205UF 0EM406573
B4# HOLDER DEGAUSS L1200UA 0EM405869
B5 CLOTH 190X15XT0.5 TS7623
B6 CLOTH(10X30XT0.5) B5900UA 0EM404486
B7 CLOTH(15X10XT0.5) L9700UA 0EM405038
CL1802 WIRE ASSEMBLY SPEAKER WIRE(180MM) WX1L9800-001
CL2801 WIRE ASSEMBLY SPEAKER WIRE(180MM) WX1L9800-001
CLN551# WIRE CRT GND(PB FREE) WX1L3420-001 WX1L3420-001
DG601# DEGAUSSING COIL LLBH00ZTM048 LLBH00ZTM048
L1 SCREW P-TIGHT 4X18 BIND HEAD + GBMP4180
L2 SCREW TAPPING M4X14 DBU14140
L4 SCREW P-TIGHT 3X10 BIND HEAD+ GBMP3100
L3-1 SCREW P-TIGHT 3X10 BIND HEAD+ GBKP3100
L3-2 SCREW P-TIGHT 3X10 BIND HEAD+ GBKP3100
SP801 SPEAKER S0407F01A DSD0807XQ001
SP1801 SPEAKER S0407F01A DSD0807XQ001
TB1 TRAY CHASSIS T1100UA 1EM020114
TB2 TOP SHIELD T1100UA 1EM320155
TB10 RCA HOLDER T1100UA 1EM420613
TB14 X6 LOADER COVER T1100UA 1EM420561
TB18 LABEL LASER CAUTION (C) TD100UA ---------
TB19# 24PF CHASSIS NO. LABEL TJ T2120UA ---------
TB23-2 WIRE HOLDER C T1100UA 1EM420615
TB30 X6 LOADER PCB HOLDER T1100UA 1EM420560
TL3 SCREW S-TIGHT 3X4 BIND HEAD+ GBMS3040
TL4 SCREW P-TIGHT 3X20 BIND HEAD + GBMP3200
TL5 P-TIGHT SCREW 3X8 BIND + GBMP3080
TL14 SCREW B-TIGHT D3X8 BIND HEAD+ GBMB3080
TL18 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
TL1-1 SCREW P-TIGHT 3X12 WASHER HEAD+ GCMP3120
TL1-2 SCREW P-TIGHT 3X12 WASHER HEAD+ GCMP3120
TL1-3 SCREW P-TIGHT 3X12 WASHER HEAD+ GCMP3120
TL1-4 SCREW P-TIGHT 3X12 WASHER HEAD+ GCMP3120
TL1-5 SCREW P-TIGHT 3X12 WASHER HEAD+ GCMP3120
PACKING
S1 CARTON T2127UH 1EM420969
S2 STYROFOAM TOP ASSEMBLY T2120UA 1EM420701
S3 STYROFOAM BOTTOM ASSEMBLY T2120UA 1EM420702
S4 SERIAL NO. LABEL T2127UH ---------
S6 SHEET SET PCEC 003502019816 0EM403887
S7 HOLD PAD T2100UA 1EM420687
S15 FRONT PAD T2120UA 1EM421066
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420
X2# OWNERS MANUAL T2127UH 1EMN20315
X3 REMOTE CONTROL 189/ERC001/NE209UD NE209UD
X4 DRY BATTERY R6P(AR)2PX XB0M451HU002
Note:
1. V501 (CRT) HAS COUPLE OF SUBSTITUTIONAL PARTS AND EACH PARTS
ALSO HAS MATCHING COMBINATION WITH L551.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
2. L551 (DEFLECTION YOKE) HAS MATCHING COMBINATION WITH V501.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
CRT TYPE A
L551# DEFLECTION YOKE(PB FREE) CDY-Q2512F LLBY00ZQS021
V501# CRT A59QDF891X TCRT190SM035
V501-1 PCM JH88DTA XM04000BV010
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE B
L551# DEFLECTION YOKE 6150Z-1230U LLBY00ZGS011
V501# CRT A59QDC280X TCRT190GS048
V501-1 PCM JH88DTA XM04000BV010
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
Ref. No. Description Part No.
