Symphonic SC724FDF - Page 88

20050425 1-19-9 T2127EL
CRT CBA
FUNCTION CBA
JUNCTION CBA
TP2505 PCB JUMPER D0.6-P5.0 JW5.0T
VR2530 CARBON P.O.T. 30k Ω B VRCB303KA011
VR2531 CARBON P.O.T. 5k Ω B VRCB502KA011
Ref. No. Description Part No.
CRT CBA (MPS-B)
Consists of the following:
----------
CAPACITORS
C2505 CERAMIC CAP.(AX) B J 390pF/50V CCA1JJT0B391
C2506 CERAMIC CAP.(AX) B J 560pF/50V CCA1JJT0B561
C2508 ELECTROLYTIC CAP. 47µF/ 25V M CE1EMASDL470
C2509 CERAMIC CAP. B K 1000pF/2KV CCD3DKP0B102
C2510 ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASDL1R0
CONNECTOR
CN2501 CONNECTOR PIN 1P RT-01N-2.3A 1730688
DIODES
D2501 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2502 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2503 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
COIL
L2501 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q2501A TRANSISTOR 2SC5360 QQ9Z02SC5360
Q2502A TRANSISTOR 2SC5360 QQ9Z02SC5360
Q2503A TRANSISTOR 2SC5360 QQ9Z02SC5360
RESISTORS
R2507 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R2508 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R2509 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R2510 CARBON RES. 1/4W J 8.2k Ω RCX4JATZ0822
R2511 CARBON RES. 1/4W J 8.2k Ω RCX4JATZ0822
R2512 CARBON RES. 1/4W J 8.2k Ω RCX4JATZ0822
R2513 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R2514 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R2515 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R2516# FIXED METAL OXIDE FILM RE S. 3W J 10k Ω RN03103DP005
R2517# FIXED METAL OXIDE FILM RE S. 3W J 10k Ω RN03103DP005
R2518# FIXED METAL OXIDE FILM RE S. 3W J 10k Ω RN03103DP005
R2519 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R2520 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R2521 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R2522 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R2523 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R2524 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
MISCELLANEOUS
JK2501# CRT SOCKET ISHS40ST JSCC290PK006
Ref. No. Description Part No.
FUNCTION CBA (MPS-C)
Consists of the following:
---------
CONNECTORS
CN2401 BOARD CONNECTOR 07P(PB FREE)
127301107K2
JCTWA07TG004
CN2801 STRAIGHT CONNECTOR BASE 00 8283 0212
00 000
J383C02UG002
RESISTORS
R2401 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
R2402 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
R2403 CARBON RES. 1/4W G 2.2k Ω RCX4GATZ0222
R2404 CARBON RES. 1/4W G 2.7k Ω RCX4GATZ0272
Ref. No. Description Part No.
R2405 CARBON RES. 1/4W G 4.7k Ω RCX4GATZ0472
R2406 CARBON RES. 1/4W G 6.8k Ω RCX4GATZ0682
R2407 CARBON RES. 1/4W G 15k Ω RCX4GATZ0153
SWITCHES
SW2401 TACT SWITCH SKQSAB SST0101AL038
SW2402 TACT SWITCH SKQSAB SST0101AL038
SW2403 TACT SWITCH SKQSAB SST0101AL038
SW2404 TACT SWITCH SKQSAB SST0101AL038
SW2405 TACT SWITCH SKQSAB SST0101AL038
SW2406 TACT SWITCH SKQSAB SST0101AL038
SW2407 TACT SWITCH SKQSAB SST0101AL038
SW2408 TACT SWITCH SKQSAB SST0101AL038
MISELLANEOUS
CL2501 LEAD WIRE 3P 420MM WX1T1000-001
C2504 CERAMIC CAP.(AX) B J 560pF/50V CCA1JJT0B561
CL2504 LEAD WIRE 5P 330MM WX1T2120-001
Ref. No. Description Part No.
JUNCTION CBA
Consists of the following:
----------
CONNECTOR
CN2504 242 SERIES CONNECTOR TUC-P05X-B1 WHT
ST
JCTUB05TG002
Ref. No. Description Part No.
