SYNAPTICON SOMANET Node 400 Hardware Manual


1.4.1.4 Connector details and mating parts
numbers
Connector
description
Manufacturer Mating part Crimping
Contact
Cable
Analog IN JST Sales America Inc. GHR-12V-S SSHL-002T-P0.2 26-30 AWG
*
Encoder Ports 1 & 2 TE Connectivity 1-215083-0 N/A Flat Cable
28 AWG
P1.27
Port 3 (Digital IO) JST Sales America Inc. GHR-08V-S SSHL-002T-P0.2 26-30 AWG
*
Power Terminal Block Phoenix Contact N/A 5859
WH005
(Alpha Wire)
EtherCAT IN/OUT Molex 510210500 ** 500588000 28-32 AWG
* Crimped cable from JST Sales America can be used, Parts number: AGHGH28K305
Note
** Housing only. Please ensure to only use shielded cables for EtherCAT communication!
Please also check out our dedicated EtherCAT node to PC cable which is specifically designed for
this purpose.
Hardware Manuals / SOMANET Node / SOMANET Node rev. E.1
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.10.2 | Built 2021-07-06 30/67
