HW-type Type A
Mission time T 20 a
Supported safety modes High, Low
Geometrical
properties
Dimensions 70 ∙ 40 ∙ 27.7 mm
Weight 96 g (incl. Heatsink)
Installation requirements
Max. installation altitude 2000 m
Pollution Degree PD 2
Supported Motors 1 x 3-phase BLDC-Motor and 1 active
brake
Attention
Servo drives including STO-SBC module shall be used only in Pollution Degree environments class
PD 2 according to IEC 61800-5-1:2007. During normal operation only non-conductive pollution
may occur, temporarily occurring conductivity caused by condensation may only be expected
when the servo drive is out of operation.
PD2 environment can be reached for example with environmentally controlled location which
does not contain conductive contamination or by using IP54 enclosure according to IEC
60529:1989 + A1:1999 + A2:2013.
Safe digital inputs (STO-SBC input)
Number of digital inputs 2 (dual-channel safety input for activating STO-
SBC function)
Digital input type according to IEC61131-2:2007 Type 1
Voltage range 0-60 VDC
Max. transient input voltage 80 VDC
Input voltage, logic 1 15-60 V
Input voltage, logic 0 0-5 V
