1.3.5 Mounting instructions
Attention
Servo drives should not be mounted in direct sunlight.
1.3.5.1 Heat dissipation
For correct functioning, the servo drive must be installed on a sufficiantly dimensioned heat conducting
surface made of a suitable material, such as aluminum.
Ensure that the servo drive is screwed properly to the heat conducting surface to facilitate the heat
transfer.
1.3.5.2 Dimensions
Hardware Manuals / SOMANET Node / SOMANET Node rev.
D.3/D.4
