Chapter 2: Hardware Setup
Add a Memory Module to Synology NAS
Optional Synology memory modules are designed to expand the memory of your Synology NAS. Follow the steps
below to install, check, or remove a memory module on your Synology NAS.
The following table shows the memory conguration for best practice:
A0 B0 Total Memory
4GB - 4GB
4GB 4GB 8GB
8 GB 8 GB 16 GB
16 GB 16 GB 32 GB
To install the memory module
1
Press and hold the power button until you hear a beep sound to shut down your Synology NAS. Disconnect all
cables from your Synology NAS to prevent any possible damage.
2
Remove the side panel:
a
Remove the 2 screws on the back of Synology NAS.
b
Pull the side panel. Place the side panel to the side.
Note:
When you remove the cover, sensitive internal components are exposed. Avoid touching anything other
than the memory assembly when removing or adding memory.
