Chapter 2: Hardware Setup
Install PCle Add-in Cards
Your Synology NAS has a PCI Express expansion slot which allows you to install 10GbE or Gigabit network
interface card for LAN port expansion.
1
You need to replace the long bracket (suited for PC) of your network
interface card with a short bracket before installing the card into your Synology NAS.
To replace a long bracket with a short one:
1
Remove the 2 screws from the long bracket of your network interface card, and then remove the bracket.
2
Replace the long bracket with a short one, and tighten the 2 screws to secure the short bracket.
To install a network interface card:
1
Press and hold the power button until you hear a beep sound to shut down your Synology NAS. Disconnect all
cables from your Synology NAS to prevent any possible damage.
2
Remove the 2 screws on the top of the back panel, and then pull the top cover in the direction as illustrated
below.
1
For more information about supported 10GbE or Gigabit network interface cards, please visit
www.synology.com
.
