Syntec 60CA - Middle Function for Workpiece Calibration

机床产品/Machine Tool Products – 60CA/60CB Simple-Type Wood Cutting Machine Operation Manual
Fenu and System Introduction– 41
•
•
•
a.
b.
c.
d.
•
a.
b.
c.
d.
e.
•
•
•
•
•
•
•
•
•
•
•
a.
b.
c.
d.
Explanation
Change the current cursor located workpiece coordinate value into (corresponding machine
coordinate value + keyed in teaching value)
Operation Method
Move cursor to the modifying workpiece coordinate
Input the teaching value
Press "Mach. Inc. Teach"
The workpiece coordinate value will then become the value of its corresponding machine
coordinate value + keyed in teaching value.
Example
Current machine coordinate of X axis is 5.000
Move cursor to the G54 X axis coordinate
Input 10.000
Press "Mach. Inc. Input"
The G54 X axis value will then become 15.000
Middle Function
Path
5 key, 8key：F3 Offset/Setting→F1 Workpiece Coord.→F5 Middle Func.
10+8 key：F3 Offset/Setting→F1 Workpiece Coord.→F5 Middle Func.
Explanation
This function helps to calibrate the middle point of workpiece before machining.
The value calculated by middle function will be input to G54~G59 workpiece coordinates for
coordinate setups.
Middle function provides 2 modes, manual mode and auto mode.
Manual Middle Function
Explanation
Set middle function to mode 0
User controls the machine with MPG and moves the machine to the end point of workpiece in X, Y
axis direction respectively to record the machine location. The system will automatically
calculate the X, Y axis value of workpiece center point.
Operation method
Move the tool with MPG, reach Px1 point in the figure and press "Px1 Set". The current location
will be set as the machine coordinate of Px1 and be recorded on the screen. The machine
coordinate of workpiece middle point in X axis direction will be calculated using Px1 and Px2, the
result will be shown in the Pxm column and Aux. Coord. X column.
Move the tool with MPG, reach Px2 point in the figure and press "Px2 Set". The current location
will be set as the machine coordinate of Px2 and be recorded on the screen. The machine
coordinate of workpiece middle point in X axis direction will be calculated using Px1 and Px2, the
result will be shown in the Pxm column andAux. Coord. X column.
Move the tool with MPG, reach Py1 point in the figure and press "Py1 Set". The current location
will be set as the machine coordinate of Py1 and be recorded on the screen. The machine
coordinate of workpiece middle point in Y axis direction will be calculated using Py1 and Py2, the
result will be shown in the Pym column and Aux. Coord. Y column.
Move the tool with MPG, reach Py2 point in the figure and press "Py2 Set". The current location
will be set as the machine coordinate of Py2 and be recorded on the screen. The machine
