机床产品/Machine Tool Products – 60CA/60CB Simple-Type Wood Cutting Machine Operation Manual
How to Operate 60 Series Controller– 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Condition:
System is on "Ready" state
INC JOG mode is selected
Operation:
Press axis direction key (X+, X-,Y+,Y-,Z+…) and machine moves toward the selected direction.
Cannot be constantly triggered like JOG or rapid JOG mode, INC JOG mode only moves once with
a fixed distance when axis direction key is pressed once
The fixed distance in INC JOG mode can be selected by percentage movements as below:
X1 ：Distance 0.001mm
X10 ：Distance 0.010mm
X100：Distance 0.100mm
These percentage movements are shared with MPG mode
MPG
Function:
Control axis movement toward the selected direction
Condition:
System is on "Ready" state
MPG mode is selected
Operation:
Press axis direction key (X+, X-,Y+,Y-,Z+…) or turn the direction switch on the manual pulse
generator for the direction to move.
Turn the dial on manual pulse generator clockwise / counterclockwise for forward / reverse
direction.
The moving distance when turning one track in MPG mode can be selected by percentage
movements as below:
X1 ：Distance 0.001mm
X10 ：Distance 0.010mm
X100：Distance 0.100mm
These percentage movements are shared with INC JOG mode
5.2.2 Machining Process
AUTO
Condition:
System is on "Ready" status
AUTO mode is selected
Operation:
Press 「CYCLE START」 button
System will machine the current machining program
System status will be switched from "Ready" to "busy" and backs to "Ready" when machining is
finished
Single Block
Function:
Excute each single block in program
Condition:
