Syntec 60CB - Parameter Settings Management; Tool Wear Compensation Settings

机床产品/Machine Tool Products – 60CA/60CB Simple-Type Wood Cutting Machine Operation Manual
Fenu and System Introduction– 53
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Note
This function is only enabled in MDI mode.
4.8.5 Parameter Set
Path
5 key, 8 key: F4 Monitor → F4 Param. Set
10+8 key: G4 Monitor→ F4 Param. Set
Explanation
Switch the screen between "Machining Parameter" and "Machining Information"
4.8.6 Tool Wear Set
Path
5 key, 8 key: F4 Monitor → F5 Tool Wear Set
10+8 key: G4 Monitor→ F5 Tool Wear Set
Description
Set the tool wear value
Actual Tool length= Tool length +Tool wear
Parameters
Tool Wear Set: Subtle tool length modification.
Note
The tool wear set value will be cleared after the corresponding tool length is set.
4.8.7 Work Record
Command:
5 Buttons type: F4 monitor-> Next->F2 work record
8 Buttons type: F4 monitor-> F7 work record
Description
Check current machining record and export to external storage device.
4.8.8 Clear Acum Cycle Time
Command:
5 Buttons type: F4 monitor-> Next->F3 Clear Acum Cycle time
8 Buttons type: F4 monitor ->F8 Clear Acum Cycle time
Function
Clear the accumulative time
4.8.9 Graph Adjust
Command:
5 Buttons type: F4 monitor-> Next->F4 Graph adjust
8 Buttons type: F4 monitor-> Next->F1 Graph adjust
Description
Zoom in/out simulation graph, this function will enable under 「Simulation Switch」is open.
