机床产品/Machine Tool Products – 60CA/60CB Simple-Type Wood Cutting Machine Operation Manual
Fenu and System Introduction– 54
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Operation
Please refer to 1.4.7 「Simulation」.
4.9 Maintain (MainFenu: F5)
Path
5 key, 8 key: F5 Maintain
10+8 key: G5 Maintain
Explanation
This function page displays system alarms, network settings, fast diagnosis, PLC parameter
settings, and controller software information.
4.9.1 Alarm
Path
5 key, 8 key: F5 Maintain → F1 Alarm
10+8 key: G5 Maintain→ F1 Alarm
Explanation
Display alarm messages on the screen.
Pending Alarm
Path
5 key, 8 key: F5 Maintain → F1 Alarm → F1 Pending Alarm
10+8 key: G5 Maintain → F1 Alarm → F1 Pending Alarm
Explanation
Display current system alarm.
Up to 20 alarms of CNC and driver can be displayed.
History Alarm
Path
5 key, 8 key: F5 Maintain → F1 Alarm → F2 History Alarm
10+8 key: G5 Maintain→F1 Alarm → F2 History Alarm
Explanation
Display the alarm history of the system.
Attention
Some alarm types will not be recorded here, ex: MACRO alarm
Save Alarm
Path
5 key, 8 key: F5 Maintain → F1 Alarm → F3 Save Alarm
10+8 key: G5 Maintain→F1 Alarm → F3 Save Alarm
Explanation
Export the alarm contents of current screen to external device.
