机床产品/Machine Tool Products – 60CA/60CB Simple-Type Wood Cutting Machine Operation Manual
Fenu and System Introduction– 29
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Add the current absolute coordinate as the value of 「G01 Linear Cutting」function in current
program.
Arc Cut Teach
Command
5buttons key: F2 Program→Next→F3 Teach→F3 Arc Cut Teach
8 buttons key: F2 Program→F6 Teach→F3 Arc Cut Teach
Function
Add current absolute coordinate as the input value of 「G02/G03 Circular Cutting」function in
current program.
Operation Method
Move the worktable to the arc center and press 「Arc Cut Teach」, current absolute coordinate will
be define as the arc center.
Move the worktable to the ending of the arc and press「Arc Cut Teach」, current absolute
coordinate will be define as the ending of the arc. Controller will automatically calculate the
relation between middle and end point and determine whether to use G02 or G03. The calculation
result will be regarded as the input value of 「G02/G03 Circular Cutting」function.
Cancel Arc Middle
Command
5 Buttons type: F2 Program→Next→F3 Teach→F4 Cancel Arc Middle
8 Buttons type: F2 Program→F6 Teach→F4 Cancel Arc Middle
Function
Clear the arc middle that had been set.
If the arc middle are not being set, this function will not enable.
Point Teach
Command
5 buttons type: F2 Program→Next→F3 Teach→F5 Point Teach
8 buttons type: F2 Program→F6 Teach→F5 Point Teach
Function
Move the worktable to the arc center and press 「Point Teach」, current absolute coordinate will be
input into current cursor location.
