SYSFORM CP375B - Specifications

4
2. Specifications
Specification
Description
Feeder system
Auto Upper Suction
Feeder capacity
3.94” / 100mm
Minimum size
1.77” x 3.54” / 45X90mm
Maximum size
14.57” x 39.37” / 370X1000mm
Paper stocks
70-450gsm
Minimum crease distance
0.04” / 1mm
Minimum crease from lead margin
0.04” / 1mm
Speed (one crease on A4 paper)
10,000 sheets / hr
Accuracy
±0.008” / ±0.2mm
Quantity of crease in one pass
32
Counter
Yes
Skew adjustment
±0.008” / ±0.2mm
Crease depth adjustment
Stepless Regulation
Blow adjustment
Stepless Regulation
Paper separator adjustment
Stepless Regulation
Feeding tray
31.5” / 800mm
Eject stacker
35.43” / 900mm
Power
115V 50/60Hz
Consumption
500W
Dimensions (H x W x D)
20.47” x 50.39” x 24.41”
520 x 1280 x 620mm
Weight
176.4 lbs / 80Kg
Note: A dedicated AC power line is required.
