System Sensor™ Smoke Sensor Model 2100ARFT
Troubleshooting
Troubleshooting
The panel fails to indicate that the sensor has been
learned.
❑ Check panel programming. If necessary, reprogram the
sensor following the steps outlined in the Programming
section.
❑ Check sensor batteries.
The sensor fails to transmit an alarm signal when in test
mode.
❑ Check sensor batteries.
❑ Check panel programming. If necessary, reprogram the
sensor following the steps outlined in the Programming
section.
Specifications
Compatibility:
60-838-95 Advent, Commander 2000 and
Custom Versions with software
versions 4.1 and later, UltraGard and
Custom Versions, CareTaker Plus
and Custom Versions with software
versions 4.0 and later, Concord,
Concord Express, Simon, Quik
Bridge Loop Receivers, and Quik
Bridge® Repeater.
60-838-95R Concord, Concord Express, Simon,
and Quik Bridge Loop Receivers.
Current: 12.5µA typical
28µA peak
54.8mA in alarm (average)
Sensitivity Test: Use canned smoke SM-200 or
equivalent
Dimensions: 2.0 × 5.0″ (without mounting
bracket)
2.0 × 5.5″ (with mounting bracket)
Temperature Range:
Operating 32° to 100°F (0° to 38°C)
Storage -4° to 140°F (-20° to 60°C)
Humidity: 90% non-condensing
Power Source: Two 3-volt lithium batteries of the
same type. UL-approved types:
Sanyo CR123A, Panasonic
CR123A, Duracell DL123A.
Sensitivity Levels:
Nominal: 1.00%/ft - 3.54%/ft obscuration
Nominal Supervisory:2.25%/ft obscuration
Nominal Close to Alarm:
LED stops blinking at 44 sec.
intervals.
Nominal at Alarm: LED blinks once per second.
Notices
Agency Listings
UL 217—Residential Installations
UL 268—Commercial Installations
CUL—S531 - M87 Standard for Smoke Alarms
FCC Part 15 Information to the User
Changes or modifications not expressly approved by Interactive Technolo-
gies, Inc. can void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions:
❑ This device may not cause harmful interference.
❑ This device must accept any interference received, including interfer-
ence that may cause undesired operation.
Changes or modifications not expressly approved by Interactive Technolo-
gies, Inc. can void the user’s authority to operate the equipment.
FCC ID: B4Z-764A-SMOKE CANADIAN IC: 867-102-1644
Patent No.: 4,855,713 and 5,686,885 and 5,686,896 and 5,761,206
ITI Advent, CareTaker, Commander, UltraGard, Quik Bridge, and Simon
are registered trademarks of Interactive Technologies, Inc. Concord, Con-
cord Express, and Learn Mode are trademarks of ITI. System Sensor is a
trademark of System Sensor.
Security
Automation
Fire Protection
Access Control
www.itii.com
T: 651/777-2690
F: 651/779-4890
I nteractive T echnologies, I nc.
2266 Second Street North
North Saint Paul, MN 55109-2900
1-800-777-1415
WIRELESS

System Sensor 2100ARFT Specifications

Power

current (typical)	12.5µA
current (peak)	28µA
current in alarm (average)	54.8mA

Operating Environment

operating temperature range	32° to 100°F (0° to 38°C)
storage temperature range	-4° to 140°F (-20° to 60°C)
humidity	90% non-condensing

Power Source

battery type	Two 3-volt lithium batteries
battery models	Sanyo CR123A, Panasonic CR123A, Duracell DL123A
battery approval	UL-approved

Sensitivity Levels

nominal sensitivity	1.00%/ft - 3.54%/ft obscuration
nominal supervisory sensitivity	2.25%/ft obscuration
nominal close to alarm	LED stops blinking at 44 sec. intervals

Weight and Dimensions

dimensions (without mounting bracket)	2.0 × 5.0″
dimensions (with mounting bracket)	2.0 × 5.5″
