System Sensor FSB-200 - Operational Information and Appendices; Operation Modes and Troubleshooting Guide

N200-25-00 14 I56-2424-04R
Appendix I. Operation Modes and Troubleshooting Guide
Modes *Red
See Note
Below
Yellow and Remote
Trouble Output
*Green
See Note Below
Remote Alarm
Output
Dual Digital Display Initiating means Comments & Troubleshooting Tips
Normal Off Off Blink Blink Off Successful completion of
initialization or detector reset
Alignment Off On Blink Blink On, Relative amount of signal
0-99, or – if automatic gain resetting, or Lo if signal is too low
Alignment Switch
Alarm On Off Off On Off Smoke, Test Filter, RTS451
Test Stations
Trouble-Drift Comp Elevated Signal
Off 3 Quick Blinks Blink Blink Off Long Term Drift Reference
Out of Range
• Sunlight into detector or reflector. • Re-Align detector.
Trouble-Drift Comp Reduced Signal
Off 2 Quick Blinks Blink Blink Off Long Term Drift Reference
Out of Range
• Clean detector and reflector.
Trouble-Signal Over Range
Off 2 Quick Blinks Blink Blink Off Increase of Reflected Signal • Inspect line of sight between detector and
reflector for reflective objects in the pathway.
Trouble-Beam Blockage Initial Response
Off 4 Quick Blinks Blink Blink Off Beam Blockage • Remove blockage.
• Faulty unit.
Trouble-Beam Blockage Long Term Response
On 4 Quick Blinks Blink On Off Beam Blockage • Remove blockage.
• Faulty unit.
Initialization- Power on
Off Blink until complete Blink Blink Off Apply Power from
discharged state.
Initialization- alignment exit
Off Blink until complete Blink Blink Off Depressing RESET switch
after alignment
Local Test (FSB-200S) Pass Result
On Blinks out amount of
drift used
Off On Off Panel or RTS451/KEY Remains in alarm until reset or time-out
Local Test (FSB-200S) Fail Result
Off On until reset or
time-out
Blink Blink Off Panel or RTS451/KEY test
input
Remains in fault until reset or time-out
Local Test (FSB-200) Fail
Off On until reset or
time-out
Blink Blink Off Panel or RTS451/KEY test
input
Remains in fault until reset or time-out
Local Test (FSB-200) Pass Result
On Blinks out amount of
drift used
Off On Off Panel or RTS451/KEY Remains in alarm until reset or time-out
Note: Green and Red LEDs are controlled by the control panel.
Blinks output by Yellow
LED and Remote Trouble
Output once the device
has passed a local
remote test:
Percent the
detector has
drifted
Number
of blinks
output
<10% None
<20% 1
<30% 2
<40% 3
<50% 4
<60% 5
<70% 6
<80% 7
<90% 8
<100% 9
