SystemAir Danvent DV


Annex9—33

1‐4mm
Fig. 7 and 8
.Sensorforcontrolofrotationmust
beinstalledbytheinstaller.The
distancemustbe1‐4mmfromthe
outmostbracketsusedforthe
assemblyoftherotorsegments.






Fig. 9
Pleasebeawareoftheheightofthe
bracketsthatareusedforthe
assemblyof
therotorsegments.
Pleaseturntherotortocheckthe
sensordonottouchanyofthe
brackets.
Fig.8
Fig.9
