SystemAir DVS series Manual

1
2
3
4
5
6
Legend
1 DHS Fan
2 VKS Automatic shutter
3 SSD Base sound absorber
4 ASK Intake chamber
5 ASS Flexible connection
6 ASF Intake fl ange
Fig. 27: Examples of the installation arrangement of a fan of the DHS series
5.1.2 Name plates
TYPE:
CAPAC
INS.CL.
WEIGHT 25 kg
B
1070236
0,6/0,28 A
50 Hz400 D/Y V~
0,26/0,17 kW
1300
IP44
DVS 355DV
5710
2012-09-28
min¹
/
/
MADE IN GERMANY
/970
1
3
4
5
6
2
TYPE:
CAPAC
INS.CL.
WEIGHT 25 kg
B
1071870
0,6/0,28 A
50 Hz400 D/Y V~
0,26/0,17 kW
1300
IP44
DVSI 355DV
2354
2012-09-27
min¹
/
/
MADE IN GERMANY
/ 970
1
3
4
5
6
2
Fig. 28: Example, name plate DVS Fig. 29: Example, name plate DVSI
TYPE:
CAPAC
INS.CL.
WEIGHT 21,5 kg
B
1072225
0,6/0,28 A
50 Hz400 D/Y V~
0,26/0,17 kW
1300
IP44
DHS 355DV
5707
2012-10-10
min¹
/
/
MADE IN GERMANY
/970
1
3
4
5
6
2
Legend
1 Type designation
2 Article number/ production number/ date of manufacture
3 Voltage / frequency / motor output
4 Current / speed min./max. / output
5 Registration Ukraine, Russia / weight / protection class
6 Capacity with 1~/ insulation class motor
Fig. 30: Example, name plate DHS
35
Roof fans - V 1.0
Description
