SystemAir Geniox Core - Flowchart - Example of the Label Placed on or with the Cabinet; Symbols in the Flowchart and Explanation about the Symbols

8
| General descriptions, dangers and warnings
System ground
TN-S
Current type AC
Frequence 50 HZ
Rated voltage
3*400 V+N+PE VAC
Control voltage
24 VDC
PSCC max
6 kA
PSCC min 650 A
Max fuse
25
Min fuse
10
Cable colors:
Protection circuit
Green/yellow
230 VAC phase Black
0 VAC neutral Blue
24 VDC Grey
0 VDC Grey
Analog/digital
Grey
D.2.3 Flowchart – example of the label placed on or with the cabinet
D.2.4 Symbols in the flowchart and explanation about the symbols
Id
Description
Symbol
BT Temperature sensor - PT1000
QM
Damper motor — on/off or spring return
QM
Damper motor – modulating – 0-10V
output |
