8.3 Physical data
WHE Units
8 - Technical Data
PAW-W5APAC 200 250
Power supply V/ph/Hz 230V/1+N/50Hz
Number of refrigerant circuits 1 1
REFRIGERANT
Type R32
CAPACITY
Nominal Cooling Capacity kW 20 25
Nominal Heating Capacity kW 23 28
EVAPORATOR
Type Plate
Number 1 1
Water flow rate (cooling ΔT 5K) m
3
/h 3,45 4,30
Water flow rate (heating ΔT 5K) m
3
/h 4,15 4,85
Minimum flow rate m
3
/h 2,00 2,50
Maximum flow rate m
3
/h 6,80 8,00
Pressure drop kPa Refer to Hydraulic features
HYDRAULIC CONNECTIONS (EVAPORATOR)
Type Threaded male
Inlet diameter inch 1-1/4" 1-1/4"
Outlet diameter inch 1-1/4" 1-1/4"
WEIGHT
Shipping weight kg 35 (including flow switch kit and filter kit)
Operating weight kg 27
DIMENSIONS
Length mm 455
Width mm 205
Height mm 550
PAW
250 500
Rated voltage V/ph/Hz 230V/1+N/50Hz
Max. absorbed power kW 0,024
Max. current FLA A 0,1
External fuses A 1
Max. cable cross-section mm
2
2,5
8.4 Electrical data
