Installation |
9
4.4 Installing the unit
The units are designed for ceiling installation. Left and right connections are possible.
Fig. 5 Installing position, left hand unit
Fig. 6 Installing position, right hand unit
Table 2 Symbol description
Symbol Description
Supply air
Exhaust air
Outdoor air
Extract air
