SystemAir Topvex FR800 User Manual

Topvex FR800, FR1600, FR3800 Operation and Maintenance Instructions
Systemair Inc.
13
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
Pressure
control EAF
Setp 1/1: 1.0
in.wg
Setp 1/2: 0.4
in.wg
Set the external pressure set
point for normal speed (1/1)
and reduced speed (1/2) for the
supply air fan.
Outdoor
comp.Setp. 1
-4°C = 0 in.wg
50°C = 0 in.wg
Act. Comp: 0
in.wg
Set the EAF pressure
compensation for the settable
outdoor temperature. The
outdoor compensation is linear
and is set using two parameter
pairs which give the value of the
compensation at two different
outdoor temperatures. The
compensation can be positive or
negative.
Shows The actual pressure
compensation.
→ Time settings → Time/Date
Set correct time and date.
→ Timer normal
speed
Set week schedule Monday to
Sunday + Holiday for normal
speed. Possible to set 2 periods
per day.
00:00 24:00 for continuous
running. 00:00 00:00 inactivates
the period.
Notethesettingsinthe
commissioning record
→ Timer reduced
speed
Set week schedule Monday to
Sunday + Holiday for reduced
speed. Possible to set 2 periods
per day.
00:00 24:00 for continuous
running. 00:00 00:00 inactivates
the period.
Notethesettingsinthe
commissioning record
→ Extended
running
Extended
running
60 min
Time in ext.
running
0 min
Set the time extended running.
Digital inputs can be used to
force the unit to start or increase
toNormalrunningalthoughthe
timer says the running mode
should be Off or Reduced
If the running time is set to 0
the unit only runs as long as the
digital input is closed.
The time the extended running
is active is monitored in “Time in
ext.Running”,
It’s also possible to set here as
well in order to shorten the initial
set period.
