SystemAir Topvex FR800 User Manual

Topvex FR800, FR1600, FR3800
Operation and Maintenance Instructions
Systemair Inc.
14
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
→ Holidays Holidays
(mm:dd)
1:01-01 – 01-02
2:09-04 – 09-10
3:01-05 – 01-05
Set up to 24 separate possible
holiday periods for a full year.
A holiday period can be any
number of consecutive days
from one and upwards.
The dates are in the format:
MM:DD
When the current date falls
within a holiday period, the
scheduler will use the setting for
theweekday“Holiday”.
→ Manual/Auto
In this menu the running mode
ofalltheconguredoutput
signal and a number of control
functions can be manually
controlled.
The supply air controller’s
output signal can be manually
set (Manual/Auto) to any value
between 0 and 100%. The
temperature output signals will
change accordingly if they are
in Auto mode. It is also possible
to manually control each of
the temperature output signals
individually.
Since leaving any of the
outputs in manual control will
disrupt the normal control,
an alarm will be generated as
soon as any output is set to a
manual mode.
Supply
Temperature
contr.
Auto
Manual set:
0.0
Set the supply air temperature
to“Auto”,“On”or“Off”.
Set the output signal between
0-100%.
The outputs Y1, Y2 and Y3, if in
Auto-mode, will follow the signal
according to the set split values.
SAF: Auto
Manual set:
0.0
EAF: Auto
Manual set:
0.0
Set the start signal for SAF
(supply air fan) & EAF (exhaust
air fan) to “Auto, Manual
full speed, Manual half
speed or Manual.
Heating
Auto
Manual set:
100.0
Set the heating to Auto,
Manual or Off.
Set the manual output 0-100%.
