Commissioning protocol
TAC 200 User’s Manual
Date Commissioned by Designation
Order no.
Drawing no.
Situated at
Remarks
P.T.O
TAC 200 Commissioning protocol
Enter the new values here!
Configuration Switch Function pos off Function pos on
1 on/off control shunt valve
2 on/off: 2 steps on/off: 3 steps
3 radiator heating floor heating
4 no sensor/thermostat room sensor or thermostat
5 room sensor EGRL room thermostat EGF1
Setpoints Default value New value Remarks
P:05 SP room, day 21 (if room sensor)
P:06 SP room, night 18 (if room sensor)
P:07 Night setback SP (°C) –10 / –2 Without/with room thermostat EGF1
P:08 Curve parallel adjustment 0
12345678
on
off
Time program 1 P:09, P10 MO TU WE TH FR SA SU
Day operation from
to
from
to
Time program 2 P:11, P12 MO TU WE TH FR SA SU
Day operation from
to
from
to
Control curve Default value New value Remarks
P:16 Max supply temperature 80 / 55 radiator / floor heating
P:17 Min supply temperature 10/10
P:18 Curve point x 1 5 / 10 radiator / floor heating; –9 - +19
P:19 Curve point y 0 18
P:20 Curve point y 1 45 / 35 radiator / floor heating
P:21 Curve point y 2 60 / 45 radiator / floor heating
