TAC AB, Feb 2000
5:2
Technical data
TAC 200 User’s Manual
5.3 Default values
Listed below are the default values, used at P:54 Restart.
P-functions in italics show display-only values.
P: Meaning Default value
P:00 Time / Mode 00:00 /Auto, with Day time op.
P:01 Room temperature -
P:02 Outdoor temperature -
P:03 Supply temperature -
P:04 Calculated supply temperature setpoint (SP)-
P:05 SetPoint room, day 21
P:06 SetPoint room, night 18
P:07 Night setback SP (°C) –10 (no room sensor: supply temp.)
–2 (room sensor EGF 1: room temp.)
P:08 Curve parallel adjustment 0
P:09 Time program 1, day-by-day Day time operation 06:00 - 22:00
P:10 Time program 1, 1-7 days Monday through Sunday
P:11 Time program 2, day-by-day 00:00 - 00:00
P:12 Time program 2, 1-7 days None
P:13 Clock hh:mm 00:00
P:14 Month.day 01.01
P:15 Year 1995
P:16 Max supply temperature 80 (radiator) / 55 (floor heating)
P:17 Min supply temperature 10 (radiator) / 10 (floor heating)
P:18 Curve point x(1) 5 (radiator) / 10 (floor heating)
P:19 Curve point y(0) 18
P:20 Curve point y(1) 45 (radiator) / 35 (floor heating)
P:21 Curve point y(2) 60 (radiator) / 45 (floor heating)
P:22 Wh / pulse 0.0 (inverted value x 1000 of P:23)
P:23 Pulses / kWh 999.0 (inverted value x 1000 of P:22)
P:24 SP max-power kW 999
P:25 Current power kW -
5.2 Mechanical
Enclosure ....................................................................... ABS-plastic
Enclosure rating ........................................................................ IP 40
Colour .................................................................... black/transparent
Weight ..................................................................................... 0.7 kg
Dimensions (WxHxD) .............................................. 144 x 96 x 94mm
when mounted in panel (panel cutout 138 x 92 mm, DIN 43 700)
22 mm will protrude, while max. 72 mm will lie behind the panel.
