t.a.c. TAC 200 User Manual

TAC AB, Feb 2000
4:1
Special functions, P:16 -
TAC 200 User’s Manual
4 Special functions, P:16 -
4.1 List of available functions
The following functions are normally only used during commissioning or if
special adjustments are required.
Values described with italics are display-only and cannot be changed. All
other values may be changed with the keys + and –.
To reach the functions beyond P:15, you must do as follows:
Press
P
and
P
at the same time.
P:16 Max supply temperature
P:17 Min supply temperature
P:18 Curve point x(1)
P:19 Curve point y(0)
P:20 Curve point y(1)
P:21 Curve point y(2)
P:22 Wh / pulse
P:23 Pulses / kWh
P:24 SP max-power kW
P:25 Current power kW
P:26 Power limit control interval (minutes)
P:27 Power limit gain (°C/kW)
P:28 Power limit I-time (minutes)
P:29 Room sensor authority
P:30 Room I-time (minutes)
P:31 Room deadzone (°C)
P:32 Max. room influence, day
P:33 Max. room influence, night
P:34 Supply P-band (°C)
P:35 Supply I-time (minutes)
P:36 Actuator stroke time (seconds)
P:37 °C x min On/Off next stage
P:38 Outdoor temperature 100% night setback
P:39 Outdoor temperature 0% night setback
P:40 Boost time (minutes)
P:41 Max-boost (°C)
P:42 Pump cut-off (=1)
P:43 Pump exercise (=1)
P:44 Outdoor temperature for pump stop (°C)
