t.a.c. TAC 200 User Manual

TAC AB, Feb 2000
2:3
General
TAC 200 User’s Manual
Wiring diagram for mixing valve
Connection to a system with a 230 V actuator.
2.2 Connections
Supply temp. sensor
Room sensor
M 10
B1 11
B2 12
B3 13
M 14
X1 15
X2 16
X3 17
M 18
Outdoor sensor
Forced day op.
Forced night op.
Pulse counter
1 L
2 N
3 PE
4 KC1
5 K1
6 K2
7 KC2
8 K3
9 K4
Pump
Other
R
B
W
M15/
M44
(230 V)
230 V L
230 V N
Connection to a system with a 24 V actuator.
Supply temp. sensor
Room sensor
M 10
B1 11
B2 12
B3 13
M 14
X1 15
X2 16
X3 17
M 18
Outdoor sensor
Forced day op.
Forced night op.
Pulse counter
1 L
2 N
3 PE
4 KC1
5 K1
6 K2
7 KC2
8 K3
9 K4
Pump
Other
R
B
W
(24 V)
230 V L
230 V N
~
24 V
Supply temp. sensor
Room sensor
M 10
B1 11
B2 12
B3 13
M 14
X1 15
X2 16
X3 17
M 18
Outdoor sensor
Forced day op.
Forced night op.
Pulse counter
1 L
2 N
3 PE
4 KC1
5 K1
6 K2
7 KC2
8 K3
9 K4
Pump
Other
230 V L
230 V N
Stage
2
Stage
1
Wiring diagram for on/off control
Connection to a system with an on/off control.
