T.I.P. WDF 10000 User Manual

Unscrew the cover of the case with the lamp inside and replace the lamp where necessary.
Carefully remove the protective quartz container. To do this, use a wide screwdriver, a coin or similar object, insert the tool in one of the notches that you can see at
the end of the case’s threading and lever up the case gently.
Clean the case and protective quartz container carefully using water and a soft rag. Remove any limescale from the quartz tube with descaling solutions. Check the
quartz tube for damage.
Reassemble in the reverse order, making sure you position the O-rings correctly.
Where necessary, grease O-rings with Vaseline.
See page 1 (1a, 2a)
Replacing the UV-C lamp:
Always disconnect the power supply before performing any maintenance work.
Unscrew the cover of the case with the lamp inside, remove the UV-C lamp and replace it with the new one. Reassemble in the reverse order, making sure you
position the O-rings correctly. Where necessary, grease O-rings with Vaseline.
The lamp must be changed by qualified personnel only.
Should you notice the quality of the water deteriorating, a considerable reduction in water flow or water coming out of the cover, proceed as follows:
- Water inlet chamber: the coarser debris settles on the bottom of the chamber.
It must be removed using the backwash valve, proceeding as follows:
with the pump still running, open the backwash valve for about ten seconds, then switch the pump off until the filter drains completely.
Switch the pump back on - the pump removes remaining debris from the bottom - and allow water to flow back through the backwash valve until the water is clear,
at which point you can close the valve.
If the valve is clogged, remove dirt inside using a suitable tool.
- Mechanical filtering with sponges: remove the sponges from the filter and rinse them under running water. Fit them back in their housing, doing your best to keep
them in the correct horizontal position. In the two-sponge version, the thinner sponge must always be placed on top.
- Wet & dry perforated screen: the screen’s holes must be kept free of debris and filaments at all times to allow water to flow through normally.
- Biological filter: bioballs must be rinsed whenever there is an excessive build-up of scale. Make sure the outlet grid is unobstructed.
Annual maintenance: clean the filter thoroughly at least once a year.
Drain the filter, remove all dirt from the bottom and wash all filtering materials with water.
During winter months, it is best to remove the whole unit, thus avoiding the danger of the unit freezing.
WARRANTY:
This product is warranted against defects in materials and workmanship for a 2-year period from the date of purchase. The warranty does not cover wear parts,
i.e. the rotor and UV-C lamp. The warranty certificate must be filled out in full by the dealer and must be sent with the unit in the event it is returned for repairs,
together with the receipt for tax purposes or equivalent document. The owner’s remedy under warranty consists in the replacement of defective parts. If improper
use, tampering or negligence can be attributed to the purchaser, user or dealer, the warranty shall become void immediately. The warranty shall also be void in the
absence of a receipt for tax purposes or equivalent document.
11
SPECIFICATIONS:
TECHNICAL DATA
mains voltage / frequency
pump absorbed power
UV-C lamp absorbed power
UV-C lamp life hours
IP protection class
maximum flow rate
maximum head
power cable pump
weight
maximum dim. of solid particles
maximum temp. of the pumped fluid
for pond up to
Ballast with schuko plug
filter dimension
Hose connection Inlet
Hose connection Outlet
Hose connection back wash
230-240 V / 50 Hz
55 W
11 W
5000 Hours
IP 54
2460 l / h
2.5 m
10 m H05RN-F
8 kg
4 mm
35°C
10.000 l
5 m H05RN-F
45 x 28 x H 30 cm
Ø 25 mm
Ø 32 mm
Ø 25 mm
WDF 10000
pump 2500 l/h
8

T.I.P. WDF 10000 Specifications

General

Brand	T.I.P.
Model	WDF 10000
Category	Water Filtration Systems
Language	English
