T Scale NHB-6000 - Load Cell Specifications

NB/NHB Series Technical Manual
- 6 -
Common Specifications
Interface
RS-232 Output Optional
Stabilisation Time
2 Seconds typical
Operating Temperature
+5°C - 40°C / 41°F - 104°F
Power supply (external)
12V/500mA or built-in rechargeable battery
6V/1.2Ah
Calibration
Automatic External
ADC
Σ-Δ
Display
16.5 mm high 6 digits LCD
with auto backlight and loading bar graph
Balance Housing
ABS Plastic, Stainless Steel platform
Pan Size
Φ80mm / Φ120mm / 140×150mm
Overall Dimensions (wxdxh)
190mm x 220mm x 60mm
Other Features and Specs
Accuracy enhancement for parts counting and
percentage weight function
3.3 Load Cell Specifications
Model No
SPL
Rated Capacity
300/ 600 / 1500 / 3000 gm
Sensitivity
0.8 ~ 1.0 mv/v
Excitation Voltage
15V
Material
Aluminum
Cable
0.3~3m Φ 4mm
Input Resistance
420Ω ±20Ω
Out put Resistance
350Ω ±5Ω
Temperature
Range
-30°C ~ +70°C
Safe overload
150%F.S
Ultimate overload
300%F.S
Error
±0.0233%F.S
Creep (20min)
±0.020%F.S
Zero Balance
0±5%mV/V
Max. Platform Size
200x200mm
