ROW weighing scales operation manual REV: C1, June 2015 ROW weighing scales operation manual
Press the UNIT key and M+ key together in the weighing mode, it
will display “F0 H-L”, press ZERO key to enter, use TARE key to select
“SET HI” or “SET LO”, press ZERO key to enter, use G/N key to move
active digit, use TARE key to change value, use UNIT key to clear value.
After you enter the value, press ZERO key to sure, press UNIT key to
escape.
4.3 Set check weighing mode
Press the UNIT key and M+ key together in the weighing mode to
enter setting mode, press TARE until display show “F3 OFF”, press
ZERO key to enter, press TARE key until display show “BEEP”, press
ZERO key to enter, press TARE key to select BP 2(check mode 2), BP3
(check mode 3), BP1(no beep), press ZERO key to sure, press UNIT
key to escape.
4.4 NOTE
The weight must be greater than 20 scale divisions for the
check-weighing to operate.
To disable the Check-Weighing function enter zero into both limits
by pressing the UNIT key and M+ key together in the weighing mode,
then the current limits are shown. then set zero and store the zero
values.
5 Accumulated Total
5.1 Note
The scale can be set to accumulate manually by pressing the M+
key. See the PARAMETERS Section for details of selecting the method
using function "F4 P RT". The accumulation function is only available
when weighing.
Please note before every accumulate operate, scale need return to
-4-
zero, and only press M+ key when stable, when weight less than 20d,
accumulate operate will be invalid.
5.2 Accumulate operate
The weight displayed will be stored in memory when the M+ key is
pressed and the weight is stable.
The display will show "ACC 1" and then the total in memory for 2
seconds before returning to normal. (after do accumulate operate, M+
indicator will turn on) If the optional RS-232 interface is installed the
weight will be output to a printer or PC.
Remove the weight, allowing the scale to return to zero and put a
second weight on. Press the M+ key, the display will show "ACC 2"
and then the new total.
Continue until all weights have been added.
*Note: after you change weighing unit, accumulate value will be clear.
5.3 memory recall
To view the totals in memory press M+ key in zero point (ZERO
indicator on).
5.4 memory clear
To clear the memory, just press UNIT key
5.5 automatically accumulate
At first, you need set scale to auto accumulate mode, Press the
UNIT key and M+ key together in the weighing mode, it will display “F0
H-L”, press TARE key until display show “f4 prt”, press ZERO key to
enter, press TARE key to select “p auto”, press ZERO key to sure, then
you need set baud rate and M+ format, print type.
After you set, AUTO indicator on.
-5-
