Stopping an Experiment
If for some reason you need to discontinue the experiment, you can stop it at any point by selecting Stop through
the instrument control software, touching the STOP key on the instrument touch screen, or by pressing the
STOP key on the keypad (Auto Q20/Q20/Q10).
Another function that stops the experiment is REJECT. However, the Reject function discards all of the data
from the experiment; the Stop function saves any data collected up to the point at which the experiment was
stopped.

TA Instruments Q20 Specifications

General

Model	Q20
Type	Differential Scanning Calorimeter (DSC)
Temperature Range	-90°C to 550°C
Heating Rate	0.1°C/min to 100°C/min
Cooling Rate	0.1°C/min to 100°C/min
Sensitivity	0.2 µW
Atmosphere	Inert, Oxidizing, Reducing
Sample Pan Type	Aluminum
