Taarup 4024 - Spring Suspension Area Check

37
1 - 2 Checking / Adjusting, if necessary, the spring suspension area
Check that the spring suspension area upwards is in the area 140 - 160 mm, as shown. Adjust, if
necessary, the spindles A of the lifting cylinders in the left hand and the right hand side, as
shown.
The visible thread length must not exceed 30 mm. Otherwise, the spindles will be
turned off the nuts.
If the adjusting area is too small, the lifting cylinder should be moved to hole B of the wheel
frame.
If the spring suspension area is changed, the balancing of the machine should be checked - see
page 35.
3
- 4 Checking / Adjusting, if necessary, the drawbar cylinder
Check that the length of the drawbar cylinder is correct in proportion to the outer width C of the
tractor. If necessary, adjust the spindle D of the cylinder.
The visible thread length must not exceed 180 mm. Otherwise, the spindle will be
turned off the cylinder.
