tado° BU01 - Extension Box Design and Mounting; Extension Box Physical Components; Mounting the Extension Box

tado° – Manual & Technical Documentation V1.1
10
Mechanical Design
Extension Box – Mechanical Design
Contact pins
Jumper
Serial number &
authentication code
Backplate wiring diagrams
Screws to fasten housing
Holes for wall mounting
Terminal blocks
Wall Mounted Backplate
2. Tighten the screws at the bottom to fasten the device
Mounting
Back of the Device
1. Hook the device into the backplate and press it down
