tado° BU01 - Product Packages; tado° Smart Thermostat Package; tado° Extension Kit Package

tado° – Manual & Technical Documentation V1.1
1
Product Packages
tado° Smart Thermostat tado° Extension Kit
• Measures temperature, humidity, noise & luminosity
• Displays the measured temperature and allows the adjustment
of operation and set point
• Controls heating when wired to the heating system
• Acts as a sensor and remote control when installed in combination with the
Extension Box (depends on the existing heating setup)
• Required for the replacement of hot water controlling programmers (UK only)
• Recommended for heating system setups without a room thermostat. The
Extension Box acts as a reciever; the Smart Thermostat as a wireless sensor and
remote control
• Controls heating based on sensor data from the tado° Smart Thermostat
• Typically installed next to the boiler or replacing an existing external controller
• Compatible with the UK standard backplate
1
2
tado° Smart Thermostat tado° Extension Boxtado° Bridge Power Adapter
USB Cable
Labels Labels 4-Wire Cable Euroblock-2 Plug RAST5-2 Plug
Screw Terminal
Screwdriver
Sticky Pads x2
Screws x2
Screws x2
Dowels x2 Dowels x2
Housing Screw
AAA Batteries x3
Insulating Caps x4
Ethernet Cable
TADO° BRIDGE & ACCESSORIES TADO° EXTENSION BOX & ACCESSORIESSMART THERMOSTAT & ACCESSORIES
link
router
internet
Place this sticker on the control panel of your heating as a reminder.
RU-CL-01
NO NC COM
A–
+
Lea ve he at ing set to
al wa ys on !
Your tado˚ Smart Thermostat turns the heating on and off.
BU-CL-01
A–
+
NL 1 234
Use the stickers to label the cables as specified in the instructions.
