TagMaster XT-3 - Electrical Data

XT-3 Reader Installation Manual & Data Sheet Doc no. 11-267 02
© TagMaster NA 23 (28)
5.3.2 Serial interfaces RS232 and RS485
Parameter Min Max Unit
Baud Rate 1.2 115.2 kb/s
5.3.3 USB
Parameter Min Max Unit
Data Rate 12 Mb/s
5.3.4 Memory
Parameter Value Unit
Flash Memory Size 16 MByte
RAM Memory Size 32 MByte
5.4 Electrical Data
Data regards the temperature range −40°C ( -40°F) to +60°C ( +140°F).
5.4.1 Radio / Antenna
Parameter Value Unit
Antenna Polarisation Circular
Antenna Gain
XT-3 eu / ext. antenna eu
XT-3 us / ext. antenna us
≤6.5
≤6.0
dBi
dBi
Output Power:
XT-3 eu / ext. antenna eu
XT-3 us / ext. antenna us
2
4
W (e.r.p)
W (e.i.r.p)
Operating Frequencies
XT-3 eu / ext. antenna eu
XT-3 us / ext. antenna us
865.6-867.6
902-928
MHz
MHz
Beamwidth
XT-3 eu / ext. antenna eu
XT-3 us / ext. antenna us
70
70
°
°
5.4.2 Power supply, J31
Parameter Value Unit Measured between pin
DC Power Supply 10–30 V 1-2, 3-4
DC Power Consumption
Typical
8.8 W 1-2, 3-4
Max DC Power
Consumption
15 W 1-2, 3-4
Isolation to Shielding and
Chassis
1500 V 1…6 to chassis
