10. INSTALLATION AND WIRING
10.1.Counting system assembly

The counting disc and the turns counter
CNTB-03B/03C
must be assembly as below.
ZEROING DISC
COUNTING SENSORS
(OPTION)
COUNTING DISC
CNTB-03B/03C
1.0
(MAX)
WINDING SPINDLE
6.0
(MIN)
ZEROING SENSOR
Unit=mm

The zeroing disc is not served with the controller. If you need a zero point for the winding
spindle, you have to make a zeroing disc as below, and assemble it with counting disc as
above.
7
1
ƶ
7
1
ƶ
3.1 x 4
R
1
0
.
0
R
1
3.
0
R
2
8
.
0
2.0
8.0
1.0
ZEROING DISC
Unit=mm
