CNC-210A Series H6681 User manual
Page
8
of 20
έᚊཝҋજѣࢨΦ
TAILY AUTOMATION CO.,LTD.
6. WINDING EXECUTION
6.1. To start winding
After set up all data items, press key
，
the winding process begins in accordance with the
set-up content. Press key to pause winding. During winding, press the key, the winding
speed can be switch between high speed and low speed.
The following key functions are available during PAUSE mode:
：
Give up the numbers of the winding turns and regress one step.
：
Finish current step and proceed to next step.
：
Continue winding.
：
Give up winding and go back to the READY mode.
6.2. Change the display mode
During winding or during PAUSE mode, press key, the DATA DISPLAY can be change the
display mode between turns or guiding traverse position.
6.3. Winding speed (RPM) display
Pressing key will cause the PIECE COUNT DISPLAY to display the spindle shaft RPM without
interrupting the counting. Pressing again will change the PIECE COUNT DISPLAY back to
displaying the piece count.
6.4. Piece counter management
Upon turning on the POWER SWITCH, PIECE COUNT DISPLAY will shows the number of piece
produced. During wining, each time the CONTROLLER goes from the START STEP to the END
STEP, the piece counter will automatically increase by one.
Preset piece counter
：
In READY mode, press key once and key in desired values followed by the key.
When the PIECE COUNTER reaches the preset value, the FINISH led will lit. [Setting range
0~99999].
Decrease piece counter
：
During READY or PAUSE mode, press the key and hold down for two seconds the piece
counter will decrease by one.
Reset piece counter
：
In any time holding down key for two seconds, it will set the piece counter to zero.
