16 Base Station Specifications TB9300 Specifications Manual
© Tait International Limited August 2022
1.4.1 120VAC Input
Transmit
AVAW
B Band
Single 50W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
825 mA
1.5 A
99 VA
175 VA
92 W
171 W
Dual 50 W base station
a
Minimum RF output power (5 W)
Maximum RF output power (50 W)
1.3 A
2.7 A
154 VA
321 VA
149 W
319 W
a. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
1.2 A
2.1 A
2.8 A
145 VA
247 VA
333 VA
140 W
244 W
331 W
G and H Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
860 mA
1.6 A
103 VA
191 VA
96 W
187 W
Dual 50W base station
b
Minimum RF output power (5 W)
Maximum RF output power (50 W)
1.3 A
2.9 A
156 VA
348 VA
152 W
345 W
b. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
1.3 A
2.1 A
2.8 A
151 VA
254 VA
338 VA
147 W
252 W
341 W
K Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
905 mA
1.7 A
109 VA
204 VA
101 W
201 W
Dual 50 W base station
c
Minimum RF output power (5 W)
Maximum RF output power (50 W)
1.3 A
2.9 A
156 VA
348 VA
152 W
345 W
c. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
1.3 A
2.2 A
3 A
156 VA
264 VA
360 VA
152 W
261 W
357 W
