126 Disassembly and Re-assembly of Radio TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 6.1 Lever points for detaching the control head from the radio body
LEVER
POINT
DETAILS OF
LEVER POINT
INDICATION OF
LEVER POINT
UNDERSIDE OF CHASSIS CONTROL HEAD
RADIO
BODY
