Tait TM8000 Series User Manual

140 Disassembly and Re-assembly of Radio TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 6.8 Illustration of the chassis showing the screws that secure the main-board assembly
BUNG FOR
AUXILIARY CONNECTOR
SCREW 2 SCREW 3 SCREW 4 SCREW 5
SCREW 1
SCREW 6 SCREW 7
PLAN VIEW
REAR VIEW
PAD TOP
CAN
DIGITAL BOARD
SEAL FOR
RF CONNECTOR
HEAT-TRANSFER BLOCK
MAIN
BOARD
PAF TOP CAN
