Tait TM8000 Series User Manual

130 Disassembly and Re-assembly of Radio TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 6.3 Plan view of the control head showing the control-head board
CONCEALED MICROPHONE (IF FITTED)
GUIDE 3
CLIP 3
SCREW 1 CLIP 1 CLIP 2
PADS FOR LEADS TO CONCEALED MICROPHONE
SPEAKER CONNECTOR
CONTROL-HEAD
BOARD
SPEAKER
CONTROL-HEAD
CONNECTOR
SCREW 3 GUIDE 4SCREW 2GUIDE 1GUIDE 2
POSITION OF CIRCUIT BOARD FOR OPTIONAL MICROPHONES
CONNECTORS FOR OPTIONAL BOARD
