134 Disassembly and Re-assembly of Radio TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 6.4 Plan view of the control head with the control-head board removed
CLIP 6 CLIP 4 CLIP 2
CLIP 5 CLIP 3 CLIP 1
SPEAKER
LCD
ELASTOMERIC STRIPS
SPACE-FRAME
APERTURE FOR MICROPHONE CONNECTOR
KEYPAD
CONCEALED MICROPHONE (IF FITTED)
APERTURE FOR SHAFT OF VOLUME-CONTROL POTENTIOMETER
LIGHT PIPES FOR STATUS LEDs
