136 Disassembly and Re-assembly of Radio TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 6.5 Lever points for removing the cover of the radio body
LEVER POINT
UPPER
SCREW
BOSS
DETAILS OF
LEVER POINT
LOWER
SCREW
BOSS
