152 Servicing of Control Head TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 7.1 Primary side of the control-head board
PADS FOR LCDPADS FOR LCD
PADS FOR LCD
PAD FOR KEY
