192 Diagnosis of Faults on Main Board TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 9.11 FCL circuitry under and adjacent the FCL TOP can
VIA BETWEEN C536 AND R357
POSITION IN WHICH TO PLACE R527
FOR FAULT-DIAGNOSIS PURPOSES
WHEN LOOP OSCILLATES
