198 Diagnosis of Faults on Main Board TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 9.13 Receiver circuitry under the IF TOP can
FCL TOP CAN
DIRC TOP CAN
SYN TOP CAN
FE TOP CAN
CDC TOP CAN
MEASUREMENT POINT
