46 General Description TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Figure 2.10 Parts of the lid assembly with an internal options board
6
TYPICAL LARGE
INTERNAL OPTIONS BOARD
5
SCREWS FOR SECURING
INTERNAL OPTIONS BOARD
OPTIONS LOOM
FOAM SEAL
COVER SEAL
LOCK-NUTSSCREWS
EXTERNAL
OPTIONS
CONNECTOR
